Nickle
We are a leading supplier of Nickel forged fittings and flanges, offering premium-quality products that deliver exceptional performance in demanding environments. Known for their superior corrosion resistance, heat resistance, and durability, our Nickel fittings and flanges are widely used in industries such as chemical processing, oil and gas, marine, and power generation. Manufactured to meet international standards, our products ensure reliability, precision, and long service life. With a focus on quality and timely supply, we provide effective solutions to meet diverse industrial requirements.
Equivalent
| Alloy | British Standard | Werkstoff Nr | UNS Designation |
|---|---|---|---|
| Ni 200/201 | BS 3075 (NA11) | 2.4060 | N02200 / N02201 |
| Ni 205 / 205 LC | – | 2.4061 | N02205 |
Chemical Compositions
| Alloy | Ni | Mn | Fe | Si | Cu | C | Ti |
|---|---|---|---|---|---|---|---|
| Ni 200 | Min 99.2 | Max 0.30 | Max 0.20 | Max 0.10 | Max 0.20 | Max 0.10 | Max 0.10 |
| Ni 201 | Min 99.2 | Max 0.30 | Max 0.20 | Max 0.10 | Max 0.20 | Max 0.05 | Max 0.10 |
| Ni 205 | Min 99.6 | Max 0.20 | Max 0.20 | Max 0.10 | Max 0.10 | Max 0.05 | Max 0.05 |
| Ni 205 LC | Min 99.6 | Max 0.20 | Max 0.20 | Max 0.10 | Max 0.10 | Max 0.02 | Max 0.05 |
Mechanical Properties
| Alloy | Tensile Strength (N/mm²) | Elongation % at L₀ = 100 mm | ||
|---|---|---|---|---|
| Min | Max | Min | Max | |
| Ni 200 / 201 | 400 | 550 | 20 | 30 |
| Ni 205 / 205 LC | 400 | 530 | 20 | 30 |
